Rice Lake 191638, 10Klb Cap, Stainless Steel Hermetically Sealed Load Cell, NTEP
Price :
$477.00
$474.00
(You save
$3.00
)
Condition:
New
SKU:
191638-1
Click Thumbnails to Enlarge
(No reviews yet)
Write a Review
| Full Scale Output: | 2.0 mV/V±0.05% current matched |
| Resistance: | (Output) 350 (± 3) ohm (Input) 400 (± 20) ohm |
| Seal Type: | Hermetically Sealed, IP69K |
| Cable Length: | 20 ft PTFE |
| Safe Overload: | 150% Full Scale |
| Product Part Number: | 191638 |
| Product Model: | RL32218S-HE-10K |
Interchangeable products for the load cells are Rice Lake RL35082HE or VPG Sensortronics 65083S. The RL32218S-HE model is similar to the RL32019S-HE but with 20 ft of PTFE cable. As with the RL32019S-HE, this model is also hermetically sealed and comes in capacities from 1,000 lb to 10,000 lb. Rated excitation: 5-10 VDC (15 V Maximum). Combined error: 0.017% full scale. Insulation resistance: > 5,000 megohms. Cable color code: (red) positive excitation (black) negative excitation (green) positive signal (white) negative signal.
2-Year Manufacturer Warranty.
