Rice Lake 191631, Stainless Steel Hermetically Sealed Load Cell, 4K lb Cap, NTEP
Price :
$482.00
$479.00
(You save
$3.00
)
Condition:
New
SKU:
191631-1
Click Thumbnails to Enlarge
(No reviews yet)
Write a Review
| Full Scale Output: | 2.0 mV/V ±0.05% current matched |
| Resistance: | (Output) 350 (± 3) ohm (Input) 400 (± 20) ohm |
| Seal Type: | Hermetically Sealed, IP69K |
| Cable Length: | 30 ft PTFE |
| Safe Overload: | 150% Full Scale |
| Product Part Number: | 191631 |
| Product Model: | RL32019S-HE-4K |
Interchangeable products for the load cells are: Rice Lake RL35082HE (30ft cable) and VPG Sensortronics 65083S (20ft cable). The RL32019S-HE is a stainless steel single-ended beam with 2 mV/V and 30 feet of PTFE jacketed cables. Hermetically sealed to IP69K for tough environments. Available from 1,000 lb to 10,000 lb. Rated excitation is 5-10 VDC (15 V Maximum). Combined Insulation resistance: >5000 megohms. Cable color code: (red) positive excitation (black) negative excitation (green) positive signal (white) negative signal.
2-Year Manufacturer Warranty.
