Rice Lake
Rice Lake 189158, 5KLE lb Cap, Large Envelope Alloy Steel Load Cell, NTEP
(No reviews yet)
Write a Review
- SKU:
- 189158-1
- UPC:
- 745809826887
- MPN:
- 189158
- Condition:
- New
- Availability:
- Ships in 2 Business Days
Description
The load cell is interchangeable with Rice Lake RL35023, VPG Sensortronics 65023A, and VPG Celtron SQB load cells. Cable color code is as follows; red is positive excitation, black is negative excitation, green is positive signal, and white is negative signal. Each load cell has 20 feet of cable and is FM approved and NTEP approved Class III, 1:5,000 from 1,000 lb to 10,000 lb. Output Resistance: 350 (± 3) ohm. Output Resistance: 350 (± 3) ohm. Temperature: Compensated range: -14° F to 104° F/-10° C to 40° C, Operating range: 0° F to 150° F/-18° C to 65° C. Rated Excitation: 10 VDC (15 V maximum). Combined Error: 0.017% full scale.
View AllClose
Additional Information
Full Scale Output: |
3.0mV/V |
Resistance: |
(Output) 350 (±3) ohm (Input) 400 (±20) ohm |
Seal Type: |
Environmentally Sealed, IP75 |
Cable Length: |
20 ft |
Safe Overload/Sideload: |
(Overload) 150% full scale (Sideload) 100% full scale |
Product Part Number: |
189158 |
Product Model: |
RL32018-5KLE |
